1. Adopt YTO diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
2. Double-function clutch, operate independently, high transmission capacity, effective and reliable, comfortable operation;
3. Gearbox using 4 × (4+2) engaging sleeve, shuttle-type gearshift, there are 16 forward gears, 8reverse gears, reasonable match between the gears, and have high efficiency;
4. Independent power take off device, smooth transmission, large capacity;
5. Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
7. Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
9. New streamlined appearance, generous, modern, fashion.
Model | YTO-X1204 |
Tractor | |
Type | 4×4 |
Overall dimensions (LxWxH) (mm) | 5040x2380x3100 |
Wheelbase (mm) | 2688.5 |
Min. ground clearance (mm) | 450 |
Min. operating mass (Kg) | 4820 |
Tyre spec. front / rear | 14.9-26 / 18.4-38 |
Wheel tread, front / rear | 1672-2003 / 1662-2262 |
Gear shift, forward / backward | 12 / 4 |
Speed range (Km/h), forward / backward | 2.19-29.63 / 4.72-13.83 |
PTO Power (Kw) | 81 |
Lifting force(KN) | 29 |
Diesel engine | |
Model | LR6B5-23 |
Type | Six cylinder, vertical, water cooled, four stroke, direct injection combustion |
Displacement (L) | 7.43 |
Rated power / speed (Kw) / (r/min) | 88.2 / 2300 |
YTO X1204 FARM TRACTOR SHIPPING IN CONTAINER WITH TYRES DISASSEMBLED. 2 UNITS CAN BE SHIPPED IN ONE 40HC CONTAINER.
Welcome to contact anytime. We will send you the best price quotation ASAP.
