Basic Parameter | Model | ET-940 |
Gross weight | 5400kg | |
Rated Load | 2000kg | |
Overall Dimension | 6500*2200*3000mm | |
Bucket capacity | 1.4m^3 | |
Max.Dumping Height | 4850mm | |
Max.Dumping Distance | 1050mm | |
Bucket width | 2.2m | |
Max. Speed | 30km/h | |
Air conditioner | Optinal | |
Pallet fork | ||
Snow bucket | ||
High dump bucket | ||
Sweeper | ||
Reverse camera | ||
4in1 bucket | ||
Quick-hitch | ||
Color | ||
Engine | Model | YUNNEI YN38GBZ |
Engine power | 76kw/102hp at rated engine speed 2400rpm | |
Pattern | Direct injection,water-cooled,turbocharged,diesel engine | |
Transmission System | Gearbox model | Hydraulic transmission |
Gear shift | 4 forward 4 reverse | |
Type | Automatic | |
Axle | Planetary rigid axles(hub) | |
Hydraulic system | Open hydraulic system/36L | |
Hydraulic pump | Fixed-displacement gear pump;open system | |
Hydraulic pressure | 16mpa/160bar | |
Drive system | Torque converter hydraulic transmission | |
Operating | Joystick control | |
working pump | Gear pump | |
Steering System | Steering System | Articulated frame steering |
Braking System | Driving brake | Hydraulic-air disc brake,caliper on both axle |
parking brake | Mechanical drum brake on gearbox | |
Tyre | Model | 17.5-25(standard) |
Pressure of tire | 0.25-0.35mpa | |
Package | 2 Units in 40HQ |
