Single drump vibratory road roller Shantui SR14M-B6
Configuration selling point
Shantui patented vibrating drum is fitted for high compaction flatness; the arrangement of the cooling air duct is optimized to improve the cooling efficiency; the rotational molded large fuel tank is reliable and extends the work duration.
Ease of maintenance and operation comfort
The large space enclosed cab of new appearance without A-pillar guarantees unobstructed vision and comfortable operation; the radiator is fitted with detachable dustproof net, the maintenance points are centrally arranged, it is convenient to observe the oil level and water level of oil tank and water tank with help of the oil dipstick and the water level indicator, the oil drain port and water outlet are led outward and the hood can be opened at a large angle for easier maintenance.
Adaptability to diverse working conditions
It is suitable for the compaction of the base course of large-scale projects such as highways, railways, airports, etc., and can compact the non-adhesive materials and semi-adhesive materials such as sand, gravel, crushed stone, rock fill, etc. It can be equipped with optional lugs, with a variety of functions, which is suitable for clay and other working conditions.
Specification of Shantui SR14M-B6
| Parameter | SR14M-B6 |
|---|---|
| External dimensions(mm) | 5960*2300*3190 |
| Engine brand | Shangchai |
| Power/speed(kW/rpm) | 103/2000 |
| Operating weight(kg) | 14000 |
| Front and rear load distribution | 7000/7000 |
| Vibration frequency low/high(Hz) | 30 |
| Minimum turning radius(mm) | 6500 |
| Excitation force(kN) | 290/145 |
| Amplitude(mm) | 2.0/1.0 |
| Gradeability | 0.3 |
| Speed(km/h) | For:2.8,5,11;Rev:2.8km,5 |
| Emissions (Indicated as per China standards) | Eu stage II |
