Rock type for mining Shantui dozer SD32W
Rock dozer Shantui SD32W is researched and developed independently on the basis of SD32 standard bulldozer in response to the demands of severe heavy-load working conditions, such as decomposed rock and frozen earth.
Engine power/speed: 235kW/2000rpm
Operating weight of whole machine: 38000kg
Technical Features of Shantui dozer SD32W,
●This product adopts hydraulic drive and hydraulic control technologies, featuring advanced and reasonable structure, stable and reliable performances, and light and flexible operations.
●The rock bulldozer is equipped with special tracks and the high strength wear-resistant blade and push rod to remarkably improve the wear resistance and especially adapt to the heavy-duty conditions such as coarse sand, stone, decomposed lithosphere, and frozen earth.
Here the rock Shantui dozer SD32W working,
Performance Parameters
| Length × width × height (mm) (excluding ripper) | 6880×4130×3640 | Operating weight(t) (excluding ripper) | 38 |
| Engine model | NTA855-C360S10 | Net power/rated speed (kW/rpm) | 235/2000 |
| Ground pressure(Mpa) | 0.107 | Blade type | Straight tilting blade Angle blade Semi-U blade |
| Blade capacity(m3) | 10 for straight tilting blade 6.2 for angle blade 11.7 for Semi-U blade |
Applicable Working Conditions.
