High reliability, High efficiency, High comfort
♦Equipped with original ISUZU engine which is imported from Japan features low engine speed, large torque, low fuel consumption. Kawasaki hydraulic system, KYB walking motor, 6470mm boom, 3190mm stick, bucket capacity 1.5m³.
♦Equipped with spacious cab which provides operator large space to operate machine. The premium suspension seat with armrests is very comfortable and it can reduce the working fatigue dramatically. Front windshield can be partially or fully retracted to the cab roof. Rearview camera is optional to get better rear vision in order to improve operation safety in jobsite.
♦The new electronic control system is adopted in order to improve the calculation speed to achieve precise operation. Automatic idle function can reduce fuel consumption and noise dramatically.
♦The main working conditions are stone mines, coal mines, metal mines, railways, highways, water conservancy and other
infrastructure, and various heavy-duty working conditions.
These features of this machine make it competent to handle harsh applications and guarantee quick and efficient work!
|
Item
|
Unit
|
Specifications
|
|
Rated Power
|
kW/rpm
|
190.5/2000
|
|
Bucket Capacity
|
m³
|
1.5
|
|
Operating Weight
|
kg
|
33600
|
|
Engine Model
|
/
|
ISUZU AA-6HK1XQP
|
|
Number of Cylinders
|
/
|
6
|
|
Max. Torque/Speed
|
N·m/rpm
|
872.8/1700
|
|
Displacement
|
L
|
7.79
|
|
Bucket Digging Force
|
kN
|
223
|
|
Arm Digging Force
|
kN
|
170
|
|
Max. Traction Force
|
kN
|
290
|
|
Max. Walking Speed
|
km/h
|
5.5
|
|
Min. Walking Speed
|
km/h
|
3.3
|
|
Rotary Speed
|
r/min
|
9.2
|
|
Gradeability
|
°
|
35
|
|
Ground Pressure
|
KPa
|
67
|
|
Max. Main Pump Flow
|
L/min
|
560
|
|
Main Safety Valve Pressure
|
MPa
|
34.3
|
|
Fuel Tank
|
L
|
630
|
|
Hydraulic Tank
|
L
|
340
|
|
Engine Oil
|
L
|
38
|
|
Shipping Length
|
mm
|
11234
|
|
Shipping Width
|
mm
|
3205
|
|
Cab Height
|
mm
|
3343
|
|
Ground Clearance of Counter weight
|
mm
|
1205
|
|
Min. Ground Clearance
|
mm
|
520
|
|
Tail Turning Radius
|
mm
|
3560
|
|
Wheel Tread
|
mm
|
3700
|
|
Track Length
|
mm
|
4630
|
|
Track Gauge
|
mm
|
2590
|
|
Track Shoe Width
|
mm
|
600
|
|
Rotary Platform Width
|
mm
|
3205
|
|
Max. Digging Height
|
mm
|
10120
|
|
Max. Dumping Height
|
mm
|
7400
|
|
Max. Digging Depth
|
mm
|
7330
|
|
Max. Vertical Digging Depth
|
mm
|
6365
|
|
Max. Digging Radius
|
mm
|
11075
|
|
Max. Ground Digging Radius
|
mm
|
10880
|
|
Min. Turning Radius
|
mm
|
4320
|
|
Boom Length
|
mm
|
6470
|
|
Arm Length
|
mm
|
3190
|
|
Track Section Number（each side）
|
/
|
45
|
|
Track Roller Number
|
/
|
7
|
