Item
|
Parameter
|
Unit
|
|
Rated load
|
5
|
t
|
|
Bucket capacity
|
3
|
m3
|
|
Dumping height
|
3090
|
mm
|
|
Dumping distance
|
1130
|
mm
|
|
Max.drawing force
|
170
|
kN
|
|
Max. traction
|
165
|
kN
|
|
Dimension
|
8185×3000×3465
|
mm
|
|
Operating weight
|
17200
|
kg
|
|
Boom lifting time
|
≤6.0
|
≤6.0
|
|
Total time of three devices
|
11
|
s
|
|
Wheelbase
|
3300
|
s
|
|
Min. turning radius (bucket outer)
|
6910
|
mm
|
|
Rated power
|
162
|
kW
|
|
Travel speed
|
I Gear (Forward/Backward)
|
0-11.5/16.5
|
km/h
|
II Gear (Forward)
|
0-38
|
km/h
|
|
Long boom parameter
|
|||
Item
|
Standard bucket
|
Coal bucket
|
|
Bucket capacity
|
2.7m³
|
3.5
|
|
Rated load
|
4.5t
|
4.0t
|
|
Dumping height
|
3710mm
|
3550mm
|
|
Dumping distance
|
1180mm
|
1300mm
|
|
Dimension
|
8870×3000×3350
|
8870×3000×3465
|
|
Number of carriers (each side)
|
–
|
2
|
|
Number of track rollers (each side)
|
–
|
6
|
|
Number of track shoes (each side)
|
–
|
38
|
|
Width of track shoe
|
mm
|
560
|
|
Track gauge
|
mm
|
2000
|
|
Ground length and ground pressure
|
mm/MPa
|
2730-0.077
|
|
Pitch
|
mm
|
216
|
|
Forward speed
|
km/h
|
0–3.6
|
|
0–6.5
|
|||
0–11.2
|
|||
Reverse speed
|
km/h
|
0–4.3
|
|
0–7.7
|
|||
0–13.2
|
