Truck with crane 12 wheel HOWO crane truck
HOWO truck crane features,
Sinotruk HOWO is one of the most famous brand trucks from China and is the most popular sale for export. The 12 wheel cargo truck with XCMG 10 ton crane makes the crane truck. Can load more than 50 tons. We offer the best price for the truck and professional shipping service.
12 wheel HOWO crane truck specification,
|
Cabin
|
Chassis Model/Brand
|
ZZ1257/ SINOTRUK HOWO
|
|
Drive configuration
|
8×4 12 wheel, Left hand drive
|
|
|
HW76 cab, with air condition and one bed
Driver and 1 passenger, FM radio , tools, Fire extinguisher |
||
|
Vehicle
Main Dimensions |
Overall dimensions (L x W x H)
|
11850x2550x3850mm
|
|
Carriage Size (L x W x H)
|
8000x2500x600mm
|
|
|
Wheel base
|
5825+1350mm
|
|
|
Wheel track (front/rear)
|
2022/1830mm
|
|
|
Approach/Departure angle
|
16/12(°)
|
|
|
Weight in KGS
|
Tare Weight
|
14500kg
|
|
Payload
|
20tons
|
|
|
Front axles loading capacity
|
HF9, 9000kg
|
|
|
Rear axles loading capacity
|
HC16, 16000kg double
|
|
|
Max. driving speed(km/h)
|
90
|
|
|
Engine
|
Brand
|
SINOTRUK
|
|
Model
|
WD615.47
|
|
|
Horse Power
|
371HP
|
|
|
Engine type
|
4 stroke direct injection diesel engine
6 cylinder in-line, turbo-charging & intercooling |
|
|
Displacement
|
9726ml
|
|
|
Emission standard
|
Euro 2
|
|
|
Gearbox
|
HW19710,10 Forwards gear & 2 reverse gear, Manual
|
|
|
Steering
|
Left hand drive, hydraulic steering with power assistance
|
|
|
Electrical system
|
Voltage 24 V
|
|
|
Batteries 2 X 12V
|
||
|
Tire
|
12.00R20, radial tire ,10 with one spare
|
|
|
XCMG 10 ton crane
|
Max. lifting weight
|
11870kg
|
|
Max. working radius
|
14.3m
|
|
|
Max. working height
|
18.2m
|
|
|
Slewing angel
|
400°
|
|
|
High-altitude operation seat
|
Yes
|
|
|
Front and Rear outriggers
|
Yes
|
|
|
Note
|
6 arms, Knuckle Boom Type
|
|
Qingdao Elite Machinery Co., Ltd as a top supplier of vehicles in China, we have more than 10 years experience. Welcome customers to contact and visit.
