40 cubic bulk cement tanker trailer price 50ton load cement tanker
3 axle 50ton 40 cubic bulk cement tanker trailer
Our tanker trailer features,
1. Bulk cement tanker trailer with all famous brand parts like FUWA axle, JOST leanding gears, WEBCO brake walve, Triangle tires.
2. Srong frame with world top class welding and high strength steel.
3. Used for cement or other bulk powder transport
Specifications of 40 cubic bulk cement tanker trailer,
| Tare Weight | About 7.5T |
| Dimension | 10000mm*2500mm*1550mm |
| Loading Capacity (T) | 48 T |
| Axle | 3 axles / 2axles, 13 T/16T/20T BPW / FUWA / Huajing /Jinsheng |
| Rim | 9.00-22.5 (special for export market) |
| Tire | 12R22.5 Double coin brand 13pieces/ 9 pieces |
| Suspension | Mechanical America Type optional/ bogie suspension |
| Spring leaf | 90(W)mm*13(Thick)mm*10 Layer |
| King pin | brand JOST optional |
| Support leg | Jost brand optional |
| Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm,
Down plate is 16mm; Material is Q345B Steel |
| Brake chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); One piece of 45L air tanks |
| ABS | Without (optional) |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Tool box | 1 piece:equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive primer, 2 coats of final paint |
| Shipping Terms: | By bulk cargo carrier, RORO |
SHIPPING IN FLAT RACK CONTAINER,
Beiben truck head for sale together with discount
