Operating Weigh t | 23,680 kg | |
Ground Pressure | 70 kPa | |
Ground Clearance | 394 mm | |
Max.Slope | 30° | |
Engine | ||
---|---|---|
Model | Weichai WD10G178E26 | |
Rated Power | 175 kW / 235 hp | |
Working Tool | ||
Blade Type | SU | |
Blade Capacity | 6.4 m³ (U 7.5 m³ ) | |
Blade Width | 3,720 mm U 4,015 mm | |
Blade height | 1,511 mm U 1,420 mm | |
Max. Blade Digging Depth | 563 mm | |
Max. Blade Lift Ground Clearance | 1,140 mm | |
Max.Output Rimpull | 350 kN | |
Maximum Digging Depth Of Ripper | 650 mm | |
Maximum Clearance Under Tip | 640 mm | |
Powertrain | ||
Type | Electronic control, Dual-path, Hydrostatic Drive | |
Travel Speed- F/R | 0 – 11.5 km/hr (Infi nitely Variable Speed Control) | |
Steering & Brake | Hydrostatic Steering, Wet, Multiple-Disc Brakes | |
Minimum Streeing Radius | 4,225 mm (Counter-rotated avaliable) | |
Undercarrige | ||
Track Shoe Width | 560 mm | |
Track Shoe Quantity | 40 piece | |
Length Of Track On Ground | 2,948 mm | |
Track Gauge | 2,000 mm | |
Track Roller Quantity | 7/Side | |
Carrier Roller Quantity | 2/Side | |
Hydraulic System | ||
Type | Pilot Control | |
Implement Hydraulic System Pressure | 19 Mpa | |
Service Refi ll Capacities | ||
Cooling system | 45 L | |
Hydrostatic Oil | 62 L | |
Implement Oil | 110 L | |
Fuel | 460 L | |
Pivot Shaft Case (each side) | 0.8 L |
Welcome to contact we will provide quotation ASAP. 10 years professional construction machinery supplying service.
