12 wheel 380hp Beiben tipper dump truck
Benz cab, axle, frame features strong quality.
Weichai engine the best and famous in world.
High capacity cargo box heavy load capacity.
Best price in China.
Beiben dump truck/8×4/Long Cab/LHD or RHD | |||
Dimension | 11000*2500*3430mm | ||
Cargo box | 7600x2300x1500mm, HYVA hydraulic lifting system; thickness: bottom 8mm, side 6mm | ||
Approaching angle/Departure angle | 26/28° | ||
Overhang(front/rear) | 1410/1720mm | ||
Wheel base | 3800+1450+1450mm | ||
Max speed | 85km/h | ||
Curb weight | 17650kg | ||
Engine | Model | Weichai WP10.380E32, water-cooled, four strokes, 6 cylinders in line, turbocharged, directly injection | |
Displacement | 9.726L/Diesel | ||
Stroke | 126/130mm | ||
Max. power | 280/2200 (kw/rpm) | ||
Max.torque | 1600/1800(N.m/rpm) | ||
Emission | Euro III | ||
Fuel tanker capacity | 300L | ||
Clutch | ∮430, Single dry frictional disc, hydraulic boosting | ||
Gearbox | 9JS180, mechanism, 9 forward gears, 1 reverse gear, manual operated | ||
Gear ratio of gear box | 12.65/8.38/6.22/4.57/3.4/2.46/1.83/1.34/1.00 R:13.22 | ||
Suspension system | Front | Non-free standing leaf spring,telescopic shock absorber with stabilizer bar suspension , 10pcs | |
Rear | Non-free standing stabilization spring, balance suspension system, 13pcs | ||
Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | |
Assistant brake | Engine exhaust brake | ||
Park brake | Potential springs pressing on middle and rear wheels | ||
Steering system | ZF8098 hydraulic steering with power assistance | ||
Frame | Strengthened Straight beam | ||
Front axle
(Mercedes Technology) |
Double-shoe pneumatic brake, non-driving steering axle | ||
Middle and Rear axle
(Mercedes Technology) |
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | ||
Tire | 315/80R22.5 tubeless tires one spare tire | ||
Electrical system | Battery | 2X12V/135Ah | |
Generator | 28V-35A | ||
Starter | 5.4Kw/24V | ||
Cabin | NG80B long cab with A/C ; Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; High back with arm seat for driver, high back seat for co-driver; |
