CE certified mini loader 2ton front loader
Specification of small size 2ton front loader
|
SPECIFICATIONS FOR ET936 2ton front loader
|
||
|
Overall Performance
|
Rated Load
|
2000 kg
|
|
Operating Weight
|
5600 kg
|
|
|
Bucket Capacity
|
1.1 m3
|
|
|
Bucket Width
|
2040 mm
|
|
|
Dumping Height
|
3500 mm
|
|
|
Dumping Reach
|
1650 mm
|
|
|
Max. Breakout Force
|
60 KN
|
|
|
Max. Gradeablity
|
30%
|
|
|
Dimensions
|
Wheelbase
|
2550 mm
|
|
Tread
|
1580 mm
|
|
|
Mini. Turning Radius
|
4790 mm
|
|
|
Mini. Ground Clearance
|
240 mm
|
|
|
Overall Size
|
6150 x2040 x2850 mm
|
|
|
Engine Equipped
|
Brand
|
HF
|
|
Model
|
4102
|
|
|
Rated Power /Speed
|
75 kW /2400 r/min
|
|
|
Max.Torque
|
340 N.m
|
|
|
Bore x Stroke
|
102mm x105 mm
|
|
|
Displacement
|
3.8 L
|
|
|
Type
|
4-Cylinder,In-line,Turbo-charged,Water-cooled
|
|
|
Engine Optional
|
YUNNEI (4102)
|
76 kW
|
|
YUCHAI(4102)
|
78 kW
|
|
|
CUMMINS(4B3.9-C100)
|
74 kW
|
|
|
Transmission & Drive
System
|
Torque Converter
|
YJ265 (Split Type)
|
|
Gearbox Type
|
Counter-shaft , Power-shift
|
|
|
Gear Shift
|
2 Forward Shift , 2 Reverse Shift (High+Low Speed)
|
|
|
Max. Speed
|
24 km/h
|
|
|
Drive Mode
|
4 x4
|
|
|
Axle
|
Medium Hub Reduction Axle
|
|
|
Hydraulic System
|
Displacement of Work Pump
|
63 mL/r
|
|
Displacement of Walk Pump
|
32 mL/r
|
|
|
Work Pressure
|
16 MPa
|
|
|
Brake & Tyre
|
Service Brake
|
Air Brake
|
|
Parking Brake
|
Drum-type Shoe Brake, Air Released
|
|
|
Tyre Model
|
16/70-20
|
|
